‘Stolt Pride’ chemical tanker

‘Stolt Pride’ chemical tanker

Stolt Pride, stainless steel parcel chemical tanker based on Deltamarin's Ch.Delta38 design
Customers: Stolt Tankers B.V., The Netherlands / Hudong-Zhonghua Shipbuilding (Group) Co. Ltd., China
Owner: Stolt Tankers B.V.
Shipyard: Hudong-Zhonghua Shipbuilding (Group) Co. Ltd.

Stainless steel parcel chemical tankers with good fuel efficiency and operational flexibility based on Deltamarin Ch.Delta38 design.

Main dimensions of the tanker:

Cargo tank capacity abt. 45,280 m3 @ 98%
LOA 185 m
Breadth 32.26 m
Draught, scantling 10.35 m
Draught, design 10.0 m
Speed, service 14.0 kn.
Deadweight, scantling abt. 38,900 t
Stainless steel tanks 39 hull tanks + 4 deck tanks

Shipbuilding order:

Six firm units

Commission for the shipowner:

  • Outline, project development and contract documentation

Commission for the yard:

  • Approval design
  • 3D modelling of cargo deck and engine room areas

Special features:

  • The hull form and propulsion arrangement are further developed from the B.Delta bulk carriers configuration.
  • With a relatively shallow draft when fully loaded, the ships will consume significantly less fuel compared to existing parcel tankers.
  • Bow thruster tunnel closing device introduced.
  • Operational flexibility with the fully stainless steel cargo tanks, cargo pumps, heating and cooling capacity.
  • The parcel tankers will meet both Marpol Annex I and Annex II cargo requirements, complying with common structural rules for oil tankers.
  • The ships will have IMO I, II and III capabilities and will be able to handle the full range of difficult-to-handle cargoes that Stolt Tankers carries.
  • Complete segregation of all cargo tanks via individual pumps and manifolds.
  • Vessels 5 and 6 will be equipped with a scrubber.

News about the project.

Four vessels of the series have already been delivered: ‘Stolt Pride’ and ‘Stolt Sincerity’ in 2016, ‘Stolt Integrity’ and ‘Stolt Tenacity’ in 2017.
(2010-2017)
