FPSO Dynamic Producer

Extended Well Testing Unit (PIPA II) Conversion

FPSO Dynamic Producer
Customers: Magnum Transcontinental Corporation, USA (Petroserv)
Owner: Magnum Transcontinental Corporation, USA (Petroserv)
Shipyard: Sembawang Shipyard, Singapore

Main dimensions of the FPSO:

Storage 492,000 bbl
Production rate 30,000 bbl/d
LOA 257.0 m
Breadth, moulded 46.0 m
Depth, moulded 22.2 m
Accommodation 112 persons
DP station keeping

Class notation (after conversion): DNV +1A1 Ship-shaped Oil Production, Storage and Drilling unit DYNPOS-AUTR-EO-HELDK.

Commission:

The commission included Basic Design of the entire EWTU vessel including deck modules, flare stack and drill floor substructure and Detail Design.

  • Basic design including Naval architecture, Structural, FEA, Hull Outfitting, Accommodation, Safety, Mechanical, P&ID´s (Marine-, Utility-, Safety- and Drilling systems), HVAC, Electrical, Instrumentation, Telecom and Procurement assistance.
  • Detail design: A TRIBON 3D model was created of the entire ship excluding the Process module. The model included all Main equipment, Piping, Ducting, Cable trays, Stairs, Ladders, Railings and Equipment foundations. Workshop drawings and MTO´s. Additionally cable routing of Electrical-, Instrumentation and Telecom systems.
(DM/2007-2008)
